ABRITES Diagnostics for Peugeot/Citroën

The Abrites diagnostics for Peugeot/ Citroën is a very competent diagnostic software which is used together with the Abrites Vehicle Diagnostic Interface (AVDI) In order to perform vehicle diagnostics as well as advanced diagnostics on Peugeot and Citroën vehicles. Some of the main characteristics of the Abrites Diagnostic Software for PSA include the following within the basic diagnostic package:

In terms of the so-called “Advanced diagnostics” the Abrites diagnostic software for PSA provides an almost unlimited functionality where almost every modern vehicle produced by Peugeot/Citroën are supported.

The reading and writing of EEPROM is supported for the engine control units in order to have a backup to repair the car in case of any issues.

Features and highlights:

ALL OF THE BELOW ARE PERFORMED COMPLETELY BY THE ON BOARD DIAGNOSTICS CONNECTOR (OBDII):

  • PIN Code Reading and key programming – the software is designed in such a way so that it can be as user-friendly as possible for easy and quick work for all our locksmith customers
  • Mileage reading and calibration for a vast variety of models for all relevant modules, which also includes disabling of cluster synchronization as well as the ability to work with all the latest models by directly updating the EEPROM
  • Reading and modifying mileage in the dashboard of newer models that without the need of disabling the synchronization
  • BSI Exchange – for all CAN and UDS protocol vehicles. The Peugeot/Citroën Built-in System Interface is a control module, essential to the vehicles. It controls a large amount of the vehicle’s operation. Given its many tasks this module is very susceptible to failure. Given the cost of a new module and the main dealer prices for an exchange of a failed BSI, the “BSI exchange” special function provides a cost effective way out for the customer, allowing a repair shop to adapt a second hand BSI in just a few mouse clicks
  • Instrument cluster Read/Update Conf data
  • BSI Read/Update Conf data
  • Instrument cluster exchange – A broken instrument cluster is an extremely hard task to undertake by any repair shop. We know that and have tried to turn it into an easy task for people who are willing to perform it (please contact the support team for supported models)
  • Reading EEPROM and FLASH from the ECUs
  • Changing the PIN code of the BSI
  • Visualization and fault log clearing for BSI modules
  • Matching virgin Engine Control Units to BSI modules
  • Visualization of the error history from the Engine control units
  • Clearing of the error history for some models
  • Service Zero Reset (a.k.a Oil reset) for all CAN protocol supporting models – an essential part of any service workshop performing maintenance, general servicing or rebuilds
  • Airbag crash data management – allows the user to clear the crash data after repairing the vehicle thus restoring the normal operation of the car after an accident – an excellent solution for any accident damage repair shop



Special functions list. All Abrites Vehicle Diagnostics Software allow you to split the special functions you require in your field of expertise in such a way, so that you do not need to buy software that will not be useful in your personal application. In the Special functions list you can choose the ones you need and you can compare their prices at shop.abrites.com (our online store).

Please note that in order to purchase a special function you need to have an AVDI (hardware interface) in order to use that special function.

Special Functions Descriptions and Pricing Below

  • Allows you to read and write the EEPROM of the EDC15, EDC17(BOOT MODE), SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;
  • Allows you to read and write the FLASH of the EDC15, EDC17(BOOT MODE), SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;
  • Reading and modifying mileage in the dashboard of EDC15
  • Allows you to read and change the PIN of EDC15, SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;
  • Allows you to modify the service intervals of EDC15, SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;
  • Allows you to read and write the EEPROM of EDC15 Engine ECUs and make Immo OFF,as well as after sales and edit service list.

Supported models are all models using the following electronic cotrol units: EDC15, EDC16, EDC17, SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806.

This function can be used independently.

400.00 Add to cart

With this special function you can read PIN codes from the BSI module. Supported models are all CAN and UDS protocol models which includes almost all models produced after 2004
This function can be used independently.

Supported models for PIN code reading :

Lancia Phedra 2008+

Peugeot Citroën
1007
206 (1,4 HDI, 2.0 HDI)*
207
306 (2.0 HDI)*
307 (2.0 HDI)*
307 2005+
208 2012+
2008 2013+
301 2012+
308
3008
508
5008
406 (2.0 HDI)*
407
607 2006+
807 2006+
Expert II
Partner (2.0 HDI)*
Ranch (2.0 HDI)*
Partner 2008+
C2
C3 (1.4 HDI)*
C3 2006+
C3 II
DS3
C4
C4 Picasso
C4 II
DS4
C5 (2.0 HDI)*
C5 2004+
C5 II 2007+
DS5
C6
C8 2007+
Jumpy II
Xsara (2.0 HDI)*
Xsara Picasso (2.0 HDI)*
Saxo (1.4 HDI)*
Berlingo (2.0 HDI)*
Berlingo 2008+
Xantia (2.0 HDI)*
Picasso (2.0 HDI)*
C-Elysee 2012+

The key learning function can be used only if the PIN code is already known. If the read security code operation was previously completed correctly, KeyLearning procedure can take the already retrieved PIN code, otherwise you have to enter the PIN code manually.

1,400.00 Add to cart

With this special function you can read and and calibrate the mileage stored in the BSI module and remove the synchronization with the instrument cluster
(i.e. The modification is performed in the BSI exclusively and after a complete ignition cycle the mileage is not restored to the original value). In the cases where the sync removal does not apply it can calibrate the mileage in the cluster exclusively. Supported models are all CAN and UDS protocol models which includes almost all models produced after 2004.
This function can be used independently.

Supported Vehicles for Calibration:

Peugeot Citroën
1007
207
307 2005+
208 2012+
2008 2013+
301 2012+
Citroën Berlingo 2008+
308
3008
508
5008
407
607 2006+
807 2006+
Expert II
Partner 2008+
C-Elysee 2012+
C2
C3 2006+
C3 II
DS3
C4
C4 Picasso
C4 II
DS4
C5 2004+
C5 II 2007+
DS5
C6
C8 2007+
Jumpy II
Lancia Phedra 2008+

BSI Exchange – allows you to read the whole content of the one BSI (JCI or Valeo CAN) and transfer it to another one. It is very important to use the same hardware type for the replacement BSI. The Valeo BSIs are two types – the old one is thick, while the new one is thin, so they can’t be mistaken. To use this special function you need to have PN012 + PN013 special fucntions. The UDS BSI modules are supported via read/write EEPROM and flash.

1,400.00 Add to cart

Screenshots
